Engine

Industrial diesel engine equipped with Full Instrumentation and Safety Shut Down System, Four Speed Transmission.
Optional Engines, Contact Strong Manufacturing for other engine options.


Mixer

Patented 12 cubic ft. Double-Drum Mixer, Hydraulically Operated via Mechanical Drive, Counter Rotating Ribbon Paddles, Rubber lined, Hydraulically Operated Mixer Door
Options include Adjustable Packing Chambers and Outboard Bearings.


Material Pump

#100 Progressive Cavity Design Pump, Chrome Rotor, Natural Rubber Stator, 12 cubic ft. Wet Material Holding Hopper, Material Hose Pressure Gauge, Variable Output 0-100gpm @0 psi
Options include 12 cubic ft. Material Blender, UHMW lining.


Material Handling System

12 Cubic ft. Skip Loading System, Hydraulic Lift and Dump


Water System

60 Gallon Water Tank, Manual Discharge Valve, Automatic Shut-off Fill Valve: Options include Hydraulic Powered Water Pump, Digital Water Meter, Analog Water Meter


Hydraulic System

Fixed Displacement Gear Pump, 30 Gallon Hydraulic Oil Reserve :Options include Variable Displacement Hydrotatic Transmission with Fixed Displacement Gear Pumps, Hydraulic Oil Cooler, 60 Gallon Hydraulic Oil Reservoir


Frame

Made of Tubular Steel, Duel Axle, 16” Tires, Torsion or Leaf Spring Suspension, Electric Brakes, Running Lights, Ball or Pintle Hitch

Rear Skip Placer
Rear Skip Placer
