Engine

John Deere Diesel, Water Cooled, Equipped with Full Instrumentation and Safety Shut Down System, Four-speed transmission.

*Optional Engines, Contact Strong Manufacturing for other engine options.

Mixer

Patented 27 Cubic Feet Double-Drum Mixer, Hydraulically Operated via Mechanical Drive, Counter Rotating Ribbon Paddles.

*Options include Rubber Liner, Adjustable Packing Chambers and Outboard Bearings, 1½ cubic yard Mixer.

Material Pump

#100 Progressive Cavity Design Pump, Chrome Rotor, Natural Rubber Stator, 27 Cubic Feet Wet Material Holding Hopper, Variable Output 0-120gpm @0 psi.

*Options include 27 cubic ft. Material Blender, Material Hose Pressure Gauge

Material Handling System
Hydraulically powered auger and ground hopper

Water System
100 Gallon Water Tank, Manual Discharge
 Valve,
2” Analog Water Meter.
Options include, Hydraulic Powered Water Pump, Digital Water Meter.

Hydraulic System
Hydraulic Oil Cooler, 60 Gallon Hydraulic Oil Reservoir
*Options include, Variable Displacement Hydrostatic Transmission with Fixed
Displacement Gear Pumps.

Frame
Made of Tubular Steel, Dual Axle, 15” Tires, Torsion or Leaf Spring Suspension, Electric
Brakes, Running Lights, Ball or Pintle Hitch
Dimensions
Length: 19” Width: 7’2” Height: 9’10” Weight
: 8000lbs.
